9.58 MVA Phase-Shifting Transformer for Türkiye Project

Case Customer FAT 34

BBELC successfully completed the Factory Acceptance Test (FAT) for a customized 9.58 MVA phase-shifting transformer for the Tuz Golu Phase II Project in Türkiye.

Project overview

Date
August 31 – September 5, 2026
Project
Tuz Golu Phase II, Türkiye
Product
ZTSFGH-9580/31.5 Phase-Shifting Transformer
Capacity
9.58 MVA
Voltage
31.5/0.69 kV
Application
Medium-Voltage VFD System

The FAT was witnessed by representatives from the Turkish end-user, Italian engineering team, and TÜV third-party inspectors. All routine and type tests were successfully completed, meeting the applicable international standards and project requirements.

Designed for integration with medium-voltage variable frequency drive (VFD) cabinets, the transformer features a customized multi-winding configuration to support multi-pulse rectification and harmonic reduction.

This successful FAT demonstrates BBELC's engineering expertise, reliable quality, and capability to support international MV drive projects.

Factory acceptance test photos

9.58 MVA phase-shifting transformer for the Tuz Golu Phase II transformer FAT in Türkiye
9.58 MVA phase-shifting transformer
Factory test control station for the Tuz Golu Phase II transformer FAT in Türkiye
Factory test control station
On-site inspection of transformer windings for the Tuz Golu Phase II transformer FAT in Türkiye
On-site inspection of transformer windings
Transformer inspection at BBELC for the Tuz Golu Phase II transformer FAT in Türkiye
Transformer inspection at BBELC
