Segmented Phase-Shifting Rectifier Transformer for Medium Voltage Drives
BBELC’s Segmented Phase-Shifting Rectifier Transformer uses a multi-winding design to reduce higher-order harmonics and improve power quality in medium voltage VFD and multi-pulse rectifier systems.
Product Introduction
Segmented Phase-Shifting Rectifier Transformer for Medium Voltage Drives
BBELC manufactures customized segmented phase-shifting rectifier transformers for medium voltage VFD systems and industrial power conversion applications. Featuring a segmented multi-winding design with optimized phase-shifting angles, these transformers help reduce higher-order harmonics and improve power quality. They are widely used in multi-pulse rectifier systems, high-power industrial drives, and other applications requiring harmonic reduction.
- Rated Voltage: up to 35 kV
- Rated Power: up to 16 MVA
- Insulation Class: F/H
- Standards: IEC/IEEE
Applications
Medium Voltage VFD Systems
Multi-Pulse Rectifier Systems
High-Power Industrial Drives
Industrial Power Conversion
Harmonic Reduction Applications
Customized Drive Systems
Product Features
Segmented multi-winding design for harmonic reduction and stable medium voltage drive operation.
Grain-Oriented Silicon Steel Core
High-quality silicon steel core helps reduce no-load losses and operating noise.
Segmented Phase-Shifting Design
Segmented winding configuration enables optimized phase-shifting angles for harmonic reduction.
Reduced Harmonic Distortion
Multi-winding phase shifting helps suppress higher-order harmonics and improve power quality.
Advanced Insulation System
Class F/H insulation materials provide reliable electrical and thermal performance.
Optimized Cooling System
Customizable AN/AF cooling options ensure effective heat dissipation and stable operation.
Medium Voltage VFD Applications
Designed for multi-pulse rectifiers, medium voltage drives, and industrial power conversion systems.
Routine Testing
Every transformer completes the full routine test sequence in accordance with GB/T 1094.11 and IEC 60076-11 before shipment, and a test report is provided with each delivery.
- 01 — Insulation resistance test
- 02 — Voltage ratio & vector group
- 03 — Load loss test
- 04 — Partial discharge level
- 05 — Withstand voltage test
- 06 — Winding resistance test
- 07 — Induction withstand voltage test
- 08 — No-load loss test
Complete routine test reports are shipped with every unit. Witnessed testing at the factory and re-testing by third-party laboratories are supported.
