27,500 kVA & 24,300 kVA Phase-Shifting Rectifier Transformer
BBELC’s 27500kVA/24300kVA high power phase shifting rectifier transformer is designed for direct power conversion in large-capacity medium voltage drive systems, providing multi-winding phase-shifted outputs for multi-pulse rectification and harmonic reduction.
Product Introduction
27,500 kVA & 24,300 kVA Phase-Shifting Rectifier Transformer
BBELC’s 27500kVA/24300kVA High Power Phase Shifting Rectifier Transformer is an advanced large-capacity dry type transformer solution, combining ultra-high power conversion capability with high safety, environmental protection, and low maintenance requirements. Designed as an alternative to traditional oil-immersed transformers, it provides reliable medium voltage power conversion through multi-winding phase-shifting technology for high-power VFD systems, rectifier applications, and safety-critical industrial environments.
- Rated Voltage: up to 35KV
- Rated Power: 27.5MVA
- Insulation Class: F/H
- Standard: IEC/IEEE
Applications
Mining & Mineral Processing
Oil & Gas Industry
Steel & Metallurgy
Cement Plants
Rail Transit Power Supply
High-Power Variable Frequency Drives
Product Features
Stable, reliable and high-performance power supply for renewable energy testing and advanced electrical systems.
20MVA+ High Power Capacity
Full copper conductors and radial cooling ducts enable compact large-capacity transformer design.
Low Partial Discharge Structure
Multi-layer continuous windings control partial discharge below 10pC.
Optimized Cooling System
Cooling ducts and forced-air ventilation improve heat dissipation under full-load operation.
Harmonic & Load Balance Optimization
Electrical design addresses harmonic content and winding current imbalance for stable temperature rise.
Low Noise & Vibration Control
Reinforcement and damping measures minimize operating noise and transport vibration risks.
Heavy-Duty Industrial Applications
Designed for VFD systems, mine hoisting, offshore platforms, vessels, nuclear power, and high-rise buildings.
Routine Testing
Every transformer completes the full routine test sequence in accordance with GB/T 1094.11 and IEC 60076-11 before shipment, and a test report is provided with each delivery.
- 01 — Insulation resistance test
- 02 — Voltage ratio & vector group
- 03 — Load loss test
- 04 — Partial discharge level
- 05 — Withstand voltage test
- 06 — Winding resistance test
- 07 — Induction withstand voltage test
- 08 — No-load loss test
Complete routine test reports are shipped with every unit. Witnessed testing at the factory and re-testing by third-party laboratories are supported.
